Technical data
with gap
ø (mm) (ceramic ferrule)
4 - 14
ø (mm) (Short cycle)
6 - 12
ø (mm) (gas)
3 - 16
Lifting range (mm)
1 - 4.5
Lifting coil voltage (V)
60 - 90
Welding cable (m/mm2)
2m / 50
Control cable (m/mm2)
2m / 4p x 1.0
(chuck) (mm)
175
(mm)
165
(cables . kg)
1.3
Damper
K22 / Option K22-D / Standard

fiber glass




Technical data
with gap
ø (mm) (ceramic ferrule)
4 - 14
ø (mm) (Short cycle)
6 - 12
ø (mm) (gas)
3 - 16
Lifting range (mm)
1 - 4.5
Lifting coil voltage (V)
60 - 90
Welding cable (m/mm2)
2m / 50
Control cable (m/mm2)
2m / 4p x 1.0
(chuck) (mm)
175
(mm)
165
(cables . kg)
1.3
Damper
K22 / Option K22-D / Standard

fiber glass




Technical data
with gap
ø (mm) (ceramic ferrule)
13 - 22
Lifting range (mm)
2.5 - 6
Lifting coil voltage (V)
60 - 90
Welding cable (m/mm2)
2m / 95
Control cable (m/mm2)
2m / 4p x 1.0
(chuck) (mm)
250
(mm)
220
(cables . kg)
1.4
Damper
O

fiber glass




Technical data
with gap
ø (mm) (ceramic ferrule)
13 - 25
Lifting range (mm)
2.5 - 6
Lifting coil voltage (V)
60 - 90
Welding cable (m/mm2)
2m / 120
Control cable (m/mm2)
2m / 4p x 1.0
(chuck) (mm)
300
(mm)
240
(cables . kg)
2.6
Damper
O

fiber glass




Technical data
with gap
ø (mm) (ceramic ferrule)
4 - 12
ø (mm) (Short cycle)
3 - 12
ø (mm) (gas)
3 - 12
Lifting range (mm)
1 - 4.5
Lifting coil voltage (V)
60 - 90
Welding cable (m/mm2)
5m / 35
Control cable (m/mm2)
5m / 4p x 1.0
(chuck) (mm)
185
(mm)
150
(cables . kg)
0.9

fiber glass




Technical data
with gap
ø (mm) (ceramic ferrule)
3 - 12
ø (mm) (Short cycle)
3 - 12
ø (mm) (gas)
3 - 12
Lifting range (mm)
1 - 4.5
Lifting coil voltage (V)
60 - 90
Welding cable (m/mm2)
5m / 35
Control cable (m/mm2)
5m / 4p x 1.0
(chuck) (mm)
185
(mm)
150
(cables . kg)
0.9

fiber glass




Technical data
with gap
ø (mm) (ceramic ferrule)
3 - 12
ø (mm) (Short cycle)
3 - 12
ø (mm) (gas)
3 - 12
Lifting range (mm)
1 - 4.5
Lifting coil voltage (V)
60 - 90
Welding cable (m/mm2)
5m / 35
Control cable (m/mm2)
5m / 4p x 1.0
(chuck) (mm)
140
(mm)
155
(cables . kg)
0.9

fiber glass
